HBR1HF Mono Band 20m HF Transceiver. This is a completely assembled and tested homebrew mono band transceiver with specifications: *. Heterodyne using 11.059200 MHz Xtal filter based on Hambuilder BritX exciter *. ADE-1 mixer *. 20m Band coverage *. SSB & CW modes *. 2x IRF 520 Final RF amplifier *. up to 25 watts RF power output (max power in CW Mode) *. CW mode using 700Hz tone modulation generated by microcontroller *. 16x2 char LCD *. Si5351 VFO and BFO synthesizer based on RTCMono controller *. Dimensions 150 x 150 x 56 mm Band Coverage : *. 20m (14.000.000 - 14.500.000), 9-15 MHz BPF, 15 MHz LPF *. Bands range are programmable, as long as not cross the BPF/LPF range The packet consist of : *. HBR1HF Transceiver set *. Condenser Microphone *. DC Cord *. Supply VCC: 12-13.8V, 6A (TX), 0.3 (RX)
