HSM1 – 50W Mono Band HF Transceiver (40m)

The HSM1 is a compact, high-performance mono-band HF transceiver operating on the 40-meter band with 50W output power. Built on SDR (Software Defined Radio) architecture, this unit processes RF signals digitally using Hilbert Transform and FIR filtering, delivering excellent audio clarity and precise modulation. Perfect for SSB and CW operators seeking a robust yet efficient transceiver with minimal setup.

Key Specifications :

* Microcontroller STM32F407
* Display 16×2 Char LCD
* 12 Bit ADC/DAC 16KHz sampling rate
* TCXO Si5351 IQ generator
* DSP untuk Hilbert, FIR, Noise Reduction,AGC,ALC
* Suply Vcc 12-13.8V DC
* Power Out 50-60Watt
* Modulasi SSB dan CW straight/iambic
* SSB filter 1600 – 3000Hz
* CW filter 300 – 600Hz
* Audio & Key socket
* FR4 double layer PCB
* Aluminum Enclosure
* Dimension 5.5 x 15 x 16 cm + 3cm for heatsink

Highlights:

Powerful 50W RF output in a compact form
High-efficiency circuit for base or portable operations
SDR-based processing with real-time digital filtering
Ideal for amateur radio operators and homebrew enthusiasts

The Package you will get :

*. 1 unit HSM1 With complete and ready to use
*. 1 DC chord
*. 1 Condenser Microphone

Handcrafted with care by Hambuilder Radiowork – for those who believe in precision signal and passion-built radios.

DISCLAIMER :

1. Purchasing this Product means being prepared to comply with the applicable requirements & policies.
2. This is a home-brew Product and is designated for personal use only.
3. Adequate knowledge in radio electronics is required in using this Product.
4. Hambuilder is not liable for any damage or error caused by users failed experiments and/or learning process.

Please contact our support team for details of product and shipping to your country.

73’s!
Hambuilder Team
